Install Minikube
May 05, 2019
In this post we’ll try and capture all of the common steps required to standup a local environment to enable test and development of applications locally. Some of the challenges we’ll address are as follows:
- is a clear-cut way to bring up an environment end-to-end
- exposing services locally to view/interact with deployed application
- managing kubectl context to switch between local development environment and potentially a remote cluster and available CLI tools to support this.
Pre-requisites
In order to get started you’ll require the follow dependencies
- Homebrew
- familiarly with running/opening your terminal, more information can be found here
- kubectl installed, following instructions here
Install
For MacOS the process is fairly straightforward via Homebrew. We simply run the following from your terminal:
brew cask install virtualbox # this will provider our hypervisor to host the kubernetes components
brew cask install minikubeConfirm you’ve installed the above services by running the following:
foo@bar:~$ minikube version
minikube version: v1.0.1foo@bar:~$ VBoxManage --version
6.0.6r130049With the required tools installed we can now start a local kubernetes cluster by running the following:
foo@bar:~$ minikube start
Once installed we can check the status of our cluster by running the following:
foo@bar:~$ minikube status
host: Running
kubelet: Running
apiserver: Running
kubectl: Correctly Configured: pointing to minikube-vm at 192.168.99.101manage context
For kubectl to be able to communicate with the expected Kubernetes cluster, we need to manage whats known as context. This is being set in your ~/.kube/config file and can be checked and updated as described below.
We can then check our kubectl context by running the following:
foo@bar:~$ kubectl config get-context contexts
CURRENT NAME CLUSTER AUTHINFO NAMESPACE
docker-for-desktop docker-for-desktop-cluster docker-for-desktop
* minikube minikube minikube Note that this output will show you what context is currently active. An alternative, and probably more effective way to manage context is via the kubectx cli tool. This can be installed by simply running brew install kubectx. With this available we can run:
foo@bar:~$ kubectx
docker-for-desktop
minikubeWe can then set our kubectl context by running the kubectx command, selecting from the live above as follows:
kubectx minikubeThis will set our kubectl context to target the minikube cluster we’ve just deployed locally.
To check that you’re kubectl context is set correctly run the following:
foo@bar:~$ kubectx cluster-info
Kubernetes master is running at https://192.168.99.101:8443
KubeDNS is running at https://192.168.99.101:8443/api/v1/namespaces/kube-system/services/kube-dns:dns/proxyYou’ll note that the IP address 192.168.99.101 is the address allocated during the minikube start command.
exposing services
Ok so let’s deploy a basic example application known as httpbin, and demonstrate how we can access this from our local machine in localhost.
Deploy the application by pasting the following:
cat <<EOF | kubectl apply -f -
apiVersion: apps/v1
kind: Deployment
metadata:
name: httpbin
labels:
app: httpbin
spec:
replicas: 1
selector:
matchLabels:
app: httpbin
template:
metadata:
labels:
app: httpbin
version: v1
spec:
containers:
- image: docker.io/kennethreitz/httpbin
imagePullPolicy: IfNotPresent
name: httpbin
ports:
- containerPort: 80
EOFThis will deploy the httpbin application into our locally running Kubernetes cluster. To interact with the state of your deployment you have a few approaches, these are described below.
get pod status
In the above resource we applied to the cluster, we created a Deployment this will translate to the creation of Pods with the specified replica factor, in this case we set a replica factor of 1.
In order to view the pods that will be scheduled and deployed run the following (the namespace will default to default if not specified in your context or with the [-n|--namespace] flags in the kubectl command).
foo@bar:~$ kubectl get pods --namespace default
NAME READY STATUS RESTARTS AGE
httpbin-5446f4d9b4-j7957 0/1 ContainerCreating 0 9s
httpbin-5446f4d9b4-j7957 1/1 Running 0 2m39sget deployment status
This status of the deployment can also be viewed, this output will represent the state that the kubernetes scheduler sees when attempting to converge on the desired replica factor.
foo@bar:~$ kubectl get deployment -n default httpbin
NAME READY UP-TO-DATE AVAILABLE AGE
httpbin 1/1 1 1 4m54sget etcd events
From my experience, one of the best mechanisms to debug and understand the state of a given workload is the view the etcd events associated with the workflow. This will provide insights into issues that the scheduler is having or unexpected errors occurring due to mis-configured resources. The output can be retrieved as follows:
foo@bar:~$ kubectl get events --namespace default -w
7m8s Normal Scheduled pod/httpbin-5446f4d9b4-j7957 Successfully assigned default/httpbin-5446f4d9b4-j7957 to minikube
7m7s Normal Pulling pod/httpbin-5446f4d9b4-j7957 Pulling image "docker.io/kennethreitz/httpbin"
4m30s Normal Pulled pod/httpbin-5446f4d9b4-j7957 Successfully pulled image "docker.io/kennethreitz/httpbin"
4m30s Normal Created pod/httpbin-5446f4d9b4-j7957 Created container httpbin
4m30s Normal Started pod/httpbin-5446f4d9b4-j7957 Started container httpbin
7m8s Normal SuccessfulCreate replicaset/httpbin-5446f4d9b4 Created pod: httpbin-5446f4d9b4-j7957
7m8s Normal ScalingReplicaSet deployment/httpbin Scaled up replica set httpbin-5446f4d9b4 to 1Once our workload has successfully been deployed we can expose it via a Service resource. In this case we’ll create a Service of type LoadBalancer. This will then let us access the service via the minikube tunnel command.
First create the following resource, copy and pasting the text directly into your terminal:
cat <<EOF | kubectl apply -f -
apiVersion: v1
kind: Service
metadata:
name: httpbin
labels:
app: httpbin
spec:
type: LoadBalancer
ports:
- name: http
port: 8000
targetPort: 80
selector:
app: httpbin
EOFThen we need to create a “tunnel” or forwarding mechanism to the minikube ip. This will then allow us to direct access services based off their assigned ClusterIP (only when it is of type: LoadBalancer). Run the following in a secondary window and keep it running in the background:
foo@bar:~$ minikube tunnel
Status:
machine: minikube
pid: 24032
route: 10.96.0.0/12 -> 192.168.99.101
minikube: Running
services: [httpbin]
errors:
minikube: no errors
router: no errors
loadbalancer emulator: no errorsNow with the Service resource applied, we can view the address that is was assigned by running the following:
foo@bar:~$ kubectl get service --namespace default
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
httpbin LoadBalancer 10.99.106.28 10.99.106.28 8000:31890/TCP 13m
kubernetes ClusterIP 10.96.0.1 <none> 443/TCP 88mNote the address I was allocated (you’ll likely get something different) is 10.99.106.28. We can hit this address on the port that we expose (8080), as follows:
foo@bar:~$ curl "http://10.99.106.28:8000/anything" -H "accept: application/json" -v
* Trying 10.99.106.28...
* TCP_NODELAY set
* Connected to 10.99.106.28 (10.99.106.28) port 8000 (#0)
> GET /anything HTTP/1.1
> Host: 10.99.106.28:8000
> User-Agent: curl/7.54.0
> accept: application/json
>
< HTTP/1.1 200 OK
< Server: gunicorn/19.9.0
< Date: Sun, 05 May 2019 04:24:18 GMT
< Connection: keep-alive
< Content-Type: application/json
< Content-Length: 298
< Access-Control-Allow-Origin: *
< Access-Control-Allow-Credentials: true
<
{
"args": {},
"data": "",
"files": {},
"form": {},
"headers": {
"Accept": "application/json",
"Host": "10.99.106.28:8000",
"User-Agent": "curl/7.54.0"
},
"json": null,
"method": "GET",
"origin": "192.168.99.1",
"url": "http://10.99.106.28:8000/anything"
}
* Connection #0 to host 10.99.106.28 left intactSo now we’ve successfully accessed the deployed service from outside the locally running kubernetes cluster.
The IP of a exposed service can by dynamically discovered via the kubectl JSONpath, an example for the service we deployed above would be:
httpbin_ip=$(kubectl get svc httpbin --namespace default -o jsonpath='{.status.loadBalancer.ingress[0].ip}')
curl $httpbin_ip:8000/anythingFuture work
One of the issues with exposing services this way is it is harder to effectively manage the IP address that would be allocated. One nice thing about the docker-for-mac approach is it exposes the first defined Service of type: Loadbalancer via VPNKit on localahost. This means you could create a ingress-controller or istio Gateway as a singular entrypoint to your local cluster, and then dynamically steer traffic based of domain, URLs, headers etc. into your target services. This simplifies how you then think about getting access to deployed services.
One solution to this could be to establish the minikube tunnel, deploy your chosen ingress controlleror istio gateway, discover the allocated ClusterIP (which is also the ExternalIP) and then edit your /etc/hosts file to map hostnames to the allocated IP. This would look like so:
/etc/hosts:
10.99.106.28 httpbin.localThen you’d be able to curl your expose service as:
curl httpbin.local:8080/anythingThis could then be scripted to support dynamically updated your /etc/hosts according to the allocated ClusterIP on the fly.
Watch this space on further content for enabling ingress to your cluster via a typical ingress-controller like nginx-ingress. Or via more sophisticated means, such as a Service Mesh construct, where a gateway can be defined to enable access to services within the “Mesh”. Such examples include Istio, Linkerd and Consul Connect.
